Upgrading PostgreSQL from 14 to 15 using Patroni in Kubernetes

Posted on Aug 28, 2023
tl;dr: To fix broken pglogical you need to recreate origin with the same name as replication slot. `SELECT * FROM pg_stat_replication_slots; SELECT pg_replication_origin_create('pgl_market_data_prod_0c0d721_sit_m6d604ee');`


We recently undertook the task of upgrading PostgreSQL (PG) from version 14 to 15. For this, we used Patroni to control the PG deployment in Kubernetes (k8s).

Enabling In-Place Upgrade

Initially, to start a deployment, we needed to enable the in-place upgrade option in the PostgreSQL operator:

  # operator will run the upgrade script after the manifest is updated and pods are rotated
  major_version_upgrade_mode: manual

Enabling Failsafe Mode

Next, we decided to enable the failsafe mode to reduce the number of failovers in a cluster.

  # enable Patroni DCS failsafe_mode feature
  enable_patroni_failsafe_mode: true

We experienced quite a lot of failovers due to temporary k8s API unavailability.

Starting the Upgrade

With all preparations done, we started the upgrade by updating the PostgresCluster manifests:

apiVersion: acid.zalan.do/v1
kind: postgresql
  allowedSourceRanges: null
    version: 14 -> 15

The upgrade itself went smoothly, but in a production cluster, pglogical replication was broken.

Fixing Broken pglogical Replication

In the logs, we found a suspicious record regarding a missing origin:

ERROR:  replication origin "pgl_market_data_prod_0c0d721_sit_m6d604ee" does not exist

Fortunately, we were not the first ones to experience this problem. The pglogical repository has an issue with exactly the same problem. There, we found a solution: we needed to use the pg_replication_origin_create function to restore the missing origin.

However, the documentation and issue did not describe what an origin is and how you need to call this function. It took me a while to figure out how we could restore them.

To do that, I created a new replication and checked existing origins. It turns out that the origin name for pglogical is equal to the replication slot name.

SELECT * FROM pg_replication_origin;

The problem got fixed by creating origins for every replication slot of pglogical:

SELECT * FROM pg_stat_replication_slots;
SELECT pg_replication_origin_create('pgl_market_data_prod_0c0d721_sit_m6d604ee');

After that, the replication got restored.
